CERDUR® CE-TZP is a completely homogeneous zirconium oxide, cerium stabilized grinding bead. It is characterized by a very high density and good wear properties. CERDUR® CE-TZP enables very long life-time as well as efficient grinding and dispersing and can therefore be used economically. CERDUR® CE-TZP is available as grinding beads in sizes from 0.4 mm to 2.8 mm in diameter.
Chemical composition
- ZrO₂ + CeO₂:
- 98 %
- other:
- 2 %
Physical properties
- Density:
- 6,2 g/cm³ (± 0,1 g/cm³)
- Schüttdichte:
- 3,9 kg/l (depending on the bead size)
- Modulus of elasticity (Gpa):
- 300
- Vickers hardness (Hv10):
- 1150–1250
- Color:
- dark-grey
- Form:
- round
- Surface:
- smooth
All details are guide values.
Standard sizes
Grinding beads in mm:
- 0,4 - 0,6
- 0,6 - 0,8
- 0,9 - 1,1
- 1,4 - 1,6
- 1,6 - 1,8
- 1,8 - 2,0
- 2,0 - 2,2
- 2,5 - 2,8
Delivery
The grinding media is supplied in canisters of 20 kg, 25 kg or 30 kg.
Storage
The grinding media should be stored dry and clean.
